Erba EM 200: Reliable Biochemistry Testing Solution

The Erba EM 200 Analyser is designed to bring high-quality biochemistry automation to laboratories of all sizes. Compact yet powerful, it combines advanced technology with a user-friendly interface to deliver consistent results and optimise workflow efficiency. For pathologists and healthcare professionals seeking accuracy, efficiency, and cost-effectiveness, the EM 200 represents a dependable option.

Why Laboratories Choose the Erba EM 200

Laboratories today face increasing demands for faster turnaround times, a wide test menu, and dependable uptime. The EM 200 biochemistry analyser addresses these needs with:

• Throughput of up to 200 photometric tests/hour (expandable to 400 tests/hour with ISE).
• Extensive test menu, covering routine chemistry profiles (LFT, KFT, Lipid, Diabetic) and specialised assays (HbA1c, ADA, Apo(A), Apo(B), Lp(a), immunoturbidimetric assays like ASO, RF, CRP).
• Cost efficiency, with minimal reagent consumption and reusable glass cuvettes.
• 97% uptime supported by strong after-sales service, ensuring workflow continuity.

Its bench-top design makes it ideal for start-up, mid-sized, and advanced clinical laboratories.

Erba EM 200 Features

Category	Specifications
System Type	Discrete, automated, random access, patient-prioritised analyser
Throughput	200 photometric tests/hour, 400 with optional ISE (Na, K, Cl, Li)
Analytical Methods	1-Point, 2-Point, Rate-A, Rate-B, Direct Potentiometry
Reaction Tray	45 permanent hard glass cuvettes
Reading Volume	180 μl
Photometry	Static photometer, 8 filters (340–700 nm)
Light Source	Tungsten Halogen Lamp
Detector	Silicon photo-diode
Sample Capacity	39 positions (sample/blank/controls/calibrators/STAT)
Reagent Capacity	50 cooled reagent positions
Sample Types	Serum, Plasma, Urine, CSF, others
Dimensions	810 x 800 x 600 mm
Weight	Approx. 120 kg
Water Consumption	<7 litres
Power Requirement	AC 220V ± 10%, 50 Hz or AC 110V ± 10%, 60 Hz, 600 VA

Erba EM 200 Working Principle

The EM200 Erba uses static photometry technology to measure absorbance, ensuring precise detection by avoiding interference from stray wavelengths or external light sources. Its optical system, equipped with eight filters, enables reliable measurement across a broad range of clinical chemistry assays.

The analyser features:

• Capacitance probes with liquid level sensing, minimise pipetting errors.
• 6-stage cuvette cleaning and 2-stage drying, ensuring consistent performance and preventing carryover.
• Onboard calibration and QC management, with multiple calibration modes (linear, multipoint, polynomial, exponential).

This combination ensures reproducible results and confidence in routine and specialised testing.

Reagent and Control Solutions

The EM 200 biochemistry analyser is supported by a wide reagent portfolio designed to fit diverse workload demands.

• Erba XL system packs for high-volume labs.
• Small system packs for mid-sized facilities.
• ITA system packs for specialised testing.

Controls and calibrators include,

• XL Multical, ADA Cal, HbA1c Cal for calibration.
• Erba Norm/Path, HbA1c Con L/H, ASO/CRP/RF Con L/H for quality control.
• EMQAS external quality assurance program, available in Basic, Advanced, and Plus formats.

Environmental and Cost Benefits

The Erba EM 200 uses permanent glass cuvettes, reducing reliance on disposable plastics and lowering long-term consumable costs. With a reading volume of only 180 μl, the analyser minimises reagent usage, resulting in significant savings for laboratories.

An 8-stage on-board laundry system eliminates contamination between tests. The advanced cleaning process supports reliable operation over extended workloads, reducing downtime. Its compact size also conserves bench space.

Erba EM 200 Uses

Routine biochemistry testing: LFT, KFT, Lipid, Diabetic profiles.
Specialized assays: HbA1c, ADA, Apo(A), Apo(B), Lp(a).
Immunoturbidimetric testing: ASO, RF, CRP.
Flexible sample types: Serum, plasma, urine, cerebrospinal fluid.

Erba EM 200 Pricing in India

The cost of the Erba EM 200 fully automated biochemistry analyser in India generally ranges between ₹4,20,000 and ₹9,50,000, depending on the configuration, warranty, optional ISE module, and service package chosen.

• Entry-level units may start around ₹4.2–4.5 lakhs.
• Standard configurations are most commonly available in the ₹5–6.5 lakh price range.
• Advanced models with ISE and extended warranties can be priced closer to ₹9 lakh and above.

Conclusion

The Erba EM 200 analyser delivers dependable performance, a comprehensive test menu, and cost efficiency in a compact design. Its combination of advanced optics, efficient reagent handling, and strong after-sales support makes it well-suited for laboratories looking to upgrade to semi-automated or fully automated biochemistry solutions.

By balancing accuracy, throughput, and affordability, the EM 200 stands out as a reliable biochemistry testing solution for pathologists and healthcare professionals across diverse laboratory settings.
